SMA female Straight RF Connector – Fits CRE086 Coaxial Cable

SMA Female Straight RF Connector for CRE086 Cable – Model SMA-K086-1

The SMA female straight cable-mount RF connector, model SMA-K086-1, is engineered for semi-rigid assemblies using the CRE086 semi-rigid coaxial cable. Operating from DC to 18 GHz with a 50 Ω impedance, VSWR ≤ 1.12, and insertion loss ≤ 0.06 √f dB, it ensures superior signal integrity in aerospace, radar, and defense-grade RF systems. Explore more variants in the SMA connector family.

High-Frequency Stability and Electrical Precision

The SMA-K086-1 offers tight impedance control and low reflection across broadband frequencies, ensuring phase linearity and low insertion loss for precision measurement and high-performance testing applications.

Durable Construction and Repeatable Contact Integrity

Built from passivated stainless steel with a gold-plated beryllium-copper (BeCu) contact, the connector delivers excellent corrosion resistance, mechanical strength, and low contact resistance through numerous mating cycles. Additional precision-engineered components can be found in RF connectors.

Reliable Solder Termination and Environmental Compliance

The cable-mount geometry ensures secure outer conductor retention and stable solder termination, minimizing passive intermodulation (PIM) and providing vibration resistance in demanding environments. This connector is fully RoHS and REACH compliant, meeting international environmental and safety standards. Explore more semi-rigid termination styles under cable-mount connectors.

Optimized Integration with CRE086 Coaxial Cable

For low reflection, high shielding efficiency, and repeatable impedance performance, pair the SMA-K086-1 connector with the CRE086 semi-rigid coaxial cable in defense-grade, aerospace, and metrology systems where reliability and precision are critical.
