SMA Male Straight RF Connector – Fits CFT420MW Coaxial Cable

SMA Male Straight RF Connector for CFT420MW Cable – Model SMA-JCFT420MW-1

The SMA male straight cable-mount RF connector, model SMA-JCFT420MW-1, is optimized for microwave-grade assemblies using the CFT420MW low-loss coaxial cable. Supporting 50 Ω impedance from DC to 18 GHz with VSWR ≤ 1.12 and insertion loss ≤ 0.06 √f dB, it ensures stable amplitude and phase linearity for broadband microwave measurement systems. Discover related interconnects within the SMA connector family.

Stable Broadband Performance and Phase Linearity

The SMA-JCFT420MW-1 connector delivers consistent impedance control and low reflection across its operating range, ensuring precise amplitude balance and phase repeatability in microwave measurement and signal analysis systems.

Precision Materials and Long-Term Reliability

Constructed from precision-machined passivated stainless steel with a gold-plated beryllium-copper (BeCu) center contact, this connector provides durable performance, low contact resistance, and excellent corrosion resistance through multiple mating cycles. Additional assemblies can be found in RF connectors.

Secure Solder Termination and Mechanical Stability

The solder-mount configuration guarantees robust cable retention and precise dielectric alignment, maintaining insertion-loss stability and phase integrity even under vibration or temperature variation. See more mounting options in cable-mount connectors.

Optimized Integration with CFT420MW Coaxial Cable

For reliable microwave transmission and high-frequency signal fidelity, pair the SMA-JCFT420MW-1 connector with the CFT420MW low-loss, phase-stable coaxial cable—ideal for production test setups and research-grade instrumentation.
