SMP Male Smooth Bore RF Connector – Stub Terminal, Thread-In, Solder

SMP Male Smooth Bore RF Connector – Stub Terminal, Thread-In, Solder, Model SMP-JYD1-S

The SMP male smooth bore RF connector – stub terminal, thread-in, solder type – is engineered for compact, high-density microwave modules requiring repeatable, low-loss connections. Operating from DC to 40 GHz with a 50 Ω impedance, this precision SMP connector ensures exceptional performance in modular and board-to-board applications.

Reliable High-Frequency Performance

Delivering VSWR ≤ 1.2 and insertion loss ≤ 0.06 √F(GHz) dB, the SMP male smooth bore connector maintains stable impedance matching and low reflection, ideal for precision RF transmission in space-constrained designs.

Precision Engineering and Compliance

Manufactured from stainless steel with gold-plated beryllium copper contacts, the SMP stub terminal connector offers outstanding conductivity and mechanical durability. Fully REACH and RoHS compliant, it performs reliably from −55 °C to +165 °C under repeated mating cycles.

Applications in High-Density Systems

The smooth bore interface allows seamless integration into stub terminal RF connectors used in microwave modules, satellite communication devices, and radar front ends where compact size and quick connectivity are essential.

Custom SMP Engineering Solutions

Mechanc provides specialized SMP RF connectors with smooth, limited, or full detent interfaces to suit specific retention and alignment needs. Explore our RF Connector Catalog for related components.
